At INTERMEASURE 2026, JFE Advantech Co., Ltd. is introducing the air leak viewer MK-770A. It is a device for visualizing compressed-air leaks from a distance.
The rear side is equipped with an ultrasonic sensor and an ultrasonic microphone, which pick up the ultrasound in leak noise and locate the source. In the booth explanation, the company says the unit was also demonstrated at a distance of about 1 m, and that under ordinary conditions it can detect targets 7 to 8 m away.
It is intended for inspecting compressors and elevated piping inside plants, including locations that require a stepladder or scaffolding. The product displays leak volume as flow rate in a simplified format and can show the energy-saving effect of repairs in monetary terms in real time.
Challenges
Solutions
FAQ
What does the MK-770A visualize?
What is the detection principle?
What kind of sites is it intended for?
View video transcript
00:00 Thank you.
00:02 We are JFE Advantech Co., Ltd.
00:05 Today, we would like to introduce the Air Leak Viewer here.
00:11 With the Air Leak Viewer, we are reproducing an air leak from this point.
00:16 It visualizes that from a distance like this.
00:21 The principle is that an ultrasonic sensor and ultrasonic microphone are embedded on the back.
00:27 It picks up the sound coming from there, the ultrasonic sound, and locates the position.
00:34 Because factories themselves have many compressors, by detecting and repairing those leaks one by one,
00:44 the concept is to lead to energy savings.
00:49 As for the principle as well, although we are doing it now at this distance, about 1 meter,
00:54 with a general unit, it can detect even objects 7 to 8 meters away.
01:00 Our development concept is not only for the piping right in front of you, but also for elevated piping, piping that you cannot reach,
01:12 and piping that you cannot reach without setting up a stepladder or scaffolding, developing it so that it can be detected from ground level on site.
01:21 In a simple way, we display the amount of leak as a flow rate.
01:27 If you know the amount of the leak, then over one year you can calculate the cost of that leak, and so on,
01:37 so this product can display in real time, for example, that repairing this leak will lead to energy savings of 10,000 yen.
Company information / Contact
JFE Advantech Co., Ltd.
- Head office location 3-48 Takabatakecho, Nishinomiya-shi, Hyogo-ken 663-8202, Japan
- Founded / Established Founded on November 14, 1973 (spun off from Kawasaki Steel Corporation)
- Employees 320 (as of the end of March 2026)
- Official website https://www.jfe-advantech.co.jp/
- Business areas Design, development, manufacturing, sales, and related services for water environment measuring instruments, measurement and diagnostic instruments, weighing instruments, and marine and river measurement instruments.
- Main products / services Submersible pressure-type water level gauge, water level gauge application measurement system, surface-velocity ultrasonic flowmeter, electromagnetic velocity and flow direction meter, water quality monitoring system, scattered-light sludge concentration meter, optical dissolved oxygen meter (DO meter), UV meter (organic pollution measuring device), NADH meter (microbial metabolic coenzyme meter), online equipment diagnostic system, equipment diagnostic instruments, vibration meter, insulation deterioration diagnostic device, corona discharge checker, handheld hardness tester, ultrasonic thickness gauge, cable diagnostic device, ultrasonic pipe wall thickness and outer diameter measuring device, crane scale, truck scale, hopper weighing scale, belt weigh constant feeder, force measurement, load cell, weighing system, CTD, comprehensive water quality meter, salinity meter, DO meter, chlorophyll meter, turbidity meter, electromagnetic current meter, ultrasonic flowmeter for rivers
